Piling Designation	Solution Type	section modulus in³ / ft	weight lbs / ft²	width in
PZC 13		24.2	21.7	27.9
PZC 14		26.0	23.7	27.9
PZC 18		33.5	24.2	25.0
PZC 19		36.1	26.4	25.0
PZC-B 25		46.5	27.4	66.8
PZC 26		48.4	31.8	27.9
PZC-B 28		51.2	29.2	66.9
PZC 28		51.3	34.0	27.9
PZC-B 29		53.3	27.9	68.2
PZC-B 29B		54.4	29.4	70.6
PZC-B 30		56.0	30.0	61.1
PZC-B 31		57.6	29.5	68.3
PZC-B 31B		57.9	30.2	67.8
PZC-B 32B		60.2	31.6	70.6
PZC-B 33B		61.1	32.0	61.1
PZC-B 33		62.3	30.5	62.5
PZC-B 34		62.9	31.1	68.3
PZC-B 34E		63.3	32.5	66.8
PZC-B 34D		63.5	32.3	67.9
PZC-B 34C		64.1	32.0	64.9
PZC-B 36E		66.5	33.9	70.7
PZC-B 36C		66.8	32.9	68.2
PZC-B 36B		67.0	32.2	62.5
PZC-B 36D		67.8	33.0	62.1
PZC-B 37B		68.0	34.3	66.9
PZC-B 37		68.0	32.5	68.3
PZC-B 38C		70.5	34.4	64.9
PZC-B 38B		70.6	34.2	70.6
PZC-B 38D		71.2	34.5	68.3
PZC-B 39D		71.7	35.0	67.8
PZC-B 39		72.1	32.4	69.3
PZC-B 39B		72.6	33.9	68.3
PZC-B 39E		72.9	35.2	67.8
PZC-B 39C		72.9	33.9	62.5
PZC-B 40C		73.7	36.5	70.7
PZC-B 40B		74.0	35.3	62.2
PZC-B 41B		76.5	36.4	70.6
PZC-B 41		76.5	36.0	68.3
PZC-B 42		77.2	35.3	68.3
PZC-B 42D		77.3	36.9	65.0
PZC-B 42B		78.4	35.5	62.6
PZC-B 42E		78.5	37.3	67.9
PZC-B 43		80.1	34.4	69.3
PZC-B 44E		80.9	39.1	70.8
PZC-B 44C		81.6	37.4	68.3
PZC-B 44B		82.4	35.3	63.5
PZC-B 44D		82.7	38.7	70.7
PZC-B 45D		82.9	38.2	62.1
PZC-B 45B		83.5	37.0	62.6
PZC-B 45C		84.3	37.2	69.3
PZC-B 46D		85.2	39.7	65.0
PZC-B 46B		85.3	35.1	69.8
PZC-B 46C		86.2	38.8	68.3
PZC-B 47C		86.7	40.0	67.8
PZC-B 47B		86.8	38.1	68.3
PZC-B 47		87.3	36.3	69.4
PZC-B 48		88.5	38.5	62.6
PZC-B 48B		90.0	41.2	70.7
PZC-B 49B		90.8	40.2	68.3
PZC-B 49		91.1	37.5	63.6
PZC-B 50		92.3	39.3	69.3
PZC-B 50B		93.0	42.6	65.1
PZC-B 51		94.1	38.2	69.4
PZC-B 52D		96.5	38.2	64.0
PZC-B 52B		96.5	37.6	69.8
PZC-B 52F		96.7	39.9	69.8
PZC-B 52G		97.1	43.9	70.8
PZC-B 53B		98.9	41.6	62.6
PZC-B 53		99.0	39.6	63.6
PZC-B 54		99.6	41.2	69.4
PZC-B 54B		100.3	43.0	68.3
PZC-B 55		102.9	39.3	69.8
PZC-B 56		105.1	41.2	69.3
PZC-B 57C		106.4	43.0	69.4
PZC-B 57B		106.4	41.6	63.7
PZC-B 58C		107.8	42.5	69.8
PZC-B 58B		108.6	41.0	64.0
PZC-B 59B		109.5	41.0	69.9
PZC-B 61		114.2	44.2	69.8
PZC-B 62		115.6	42.9	64.1
PZC-B 63C		116.7	43.1	69.9
PZC-B 63D		117.3	46.1	69.3
PZC-B 64		118.3	44.9	63.6
PZC-B 65C		120.9	45.9	69.9
PZC-B 66		122.8	44.7	64.1
PZC-B 67		123.7	45.1	69.9
PZC-B 69B		128.0	47.9	69.9
PZC-B 70C		130.6	46.9	64.1
PZC-B 72		133.3	47.8	70.0
PZC-B 73C		135.0	49.9	69.9
PZC-B 74B		136.9	49.7	83.8
PZC-B 74		138.3	49.1	64.2
PZC-B 78B		144.6	52.6	70.0
PZC-B 80B		148.7	52.1	64.2
PZC-B 84		155.5	54.0	83.8
PZC-B 89B		166.0	56.8	83.9
PZC-B 95C		177.1	59.6	84.0
PZC-B 102		188.9	63.0	84.0
PZC-B 108		200.6	66.4	84.1
PZC-B 116		216.4	70.8	84.3
PZC-B 121		225.8	74.8	84.3
PZC-B 126		235.1	76.0	78.5

Gerdau Ameristeel is the largest producer of steel sheet piling in North America. With an annual capacity to manufacture more than 12 million tons of mill finished products, it is the fourth largest steel company and the second largest minimill steel producer in North America. Through an integrated network of minimills, steel scrap recycling facilities, and downstream operations, Gerdau Ameristeel provides service and products to customers around the world.

In September of 2007, Gerdau Ameristeel acquired Chaparral, including its operations that produce hot-rolled sheet piling. “Chaparral Sheet Piling” has now been re-branded to “Gerdau Sheet Piling.”

For further information or to request a quote, please click on the particular designation that meets your required section modulus.

Gerdau Ameristeel’s common shares are traded on the New York Stock Exchange under the symbol GNA. The company is headquartered in Toronto, with executive offices in Tampa, Florida.

For more information about Gerdau Ameristeel, visit our company website: GerdauAmeristeel.com

Many piling designations are in stock and immediately available. All products listed can usually be delivered within 4 to 8 weeks.
